Electrical engineering design software

Existing customer? Login

Streamlining your electrical design workflow

Add in applications for Autodesk® Revit®


2D electrical interface for Revit® MEP

Featured Image


Simplifying the build of your Electrical Revit Model

Featured Image


Detailed electrical design

Featured Image

About Us

For more than 25 years, PowerCad has been designing software tools for consulting engineers and electrical contractors. From the beginning, we’ve been developing fresh ways to combine electrical design theory with CAD drafting services. We’re focused on the tools to design and analyse your power distribution network and then easily move it into AutoCAD or Revit MEP. Meet your design requirements the first time.

Innovative Software

Precise Design

Model simple to complex Power Distribution Networks with speed and accuracy. Using built-in design method and compliance checking, be confident your model will work as planned in the field.

Easy Installation

All PowerCad applications run in standard Windows OS. Installation automatically adds PowerCad commands to your AutoCAD and Revit MEP Command Ribbons.

Autodesk Authorized Developer

We provide the best streamlined workflow between your electrical design and CAD-based project detailing.

Exceeding Your Expectations

In-app help guides, online, on the phone. We’ve got the support you want. Live training workshops available too. Guaranteed compatibility with AutoCAD 2005 and onwards, Revit MEP 2014 and onwards. We’re committed to your ongoing evolution.
